Master Bond offers a wide variety of electrically conductive adhesives with a nickel filler. Both one and two component systems are available for use. These compounds provide a more cost effective solution than silver filled grades for applications that require low volume resistivity. They also feature outstanding resistance to water and chemicals.
Applications of Nickel Filled, Electrically Conductive Systems
Master Bond nickel filled adhesives offer high physical strength, superior substrate adhesion and uniform conductivity even upon exposure to hostile environmental conditions. Long-term durability is excellent. Common applications include:
- Assembly and repair of PCBs
- EMI/RFI shielding
- Bond conductive gaskets
- Ground chassis and electronic boxes
- RFID tagging
Most Popular Electrically Conductive Nickel Filled Polymer Systems
 |
EP76M Nickel filled electrically conductive epoxy adhesive. Volume resistivity 5-10 ohm-cm. Cures at ambient temperatures. Convenient one to one mix ratio weight or volume. Serviceable from -60°F to +250°F. High compressive strength. Low shrinkage. Useful for applications requiring shielding and static dissipation. |
 |
EP21TDCNFL Two component nickel conductive epoxy adhesive. High flexibility. Excellent peel strength. Service temperature range from 4K to +250°F. Low shrinkage upon cure. Resists a wide range of chemicals. Volume resistivity 5-10 ohm-cm. Convenient one to one mix ratio by weight or volume. |
 |
EP76M-F Fast setting nickel filled electrically conductive epoxy adhesive. Room temperature curing. Volume resistivity 5-10 ohm-cm. Serviceable from -60°F to +250°F. Convenient one to one mix ratio weight or volume. Paste consistency. Good resistance to chemicals. High bond strength. |
 |
EP21TDCN Nickel conductive epoxy adhesive. Volume resistivity is 5-10 ohm-cm. 100% reactive. Superior toughness. One to one mix ratio by weight or volume. Smooth paste viscosity. Ambient temperature cures or fast elevated temperature cures. Service operating temperature range from -100°F to +275°F. High bond strength. |
 |
EP3HTN Nickel filled electrically conductive epoxy adhesive has a rapid cure speed. Low volume resistivity and high temperature resistance. Superior bond strength. Thermally conductive. Smooth paste, consistency. Dispensible from syringe applicator. Serviceable from -60°F to +400°F. |
 |
Supreme 10HTN-NV High peel and shear strength single component nickel filled epoxy adhesive. Thixotropic system. Cost effective electrical conductivity. Resists from 4k to +400°F. |
